Over Fascia Roof Eaves Vent - 10,000mm²/m Free Vent Area - 10mm x 1m

Over Fascia Roof Eaves Vent - 10,000mm²/m Free Vent Area - 10mm x 1m is an over-fascia eaves vent designed to improve airflow into the roof void, helping reduce condensation and prevent moisture build-up at the eaves.

It sits externally at eaves/roof level over the fascia board before the roof covering is fitted, creating a continuous ventilation path into the loft space. It is normally used with felt support trays or eaves protection systems to keep the airflow route open above insulation.

Best for

• conventional cold pitched roofs
• New-build, re-roofing and roofline refurbishment
• Loft-level airflow at the eaves without relying on soffit boards
• 1m sections where shorter runs or smaller repairs are needed

Key features

• 10,000mm²/m equivalent free vent area
• Helps reduce condensation at eaves and loft level
• Improves airflow continuously along the roof edge
• Prevents birds and large insects entering the ventilation gap where specified
• Can be installed with or without soffit depending on roofline design

Compatible with / used with

• Used with fascia boards, eaves support trays, felt support trays and pitched roof underlays
• Suitable with slate, concrete tile and clay tile roof coverings when the eaves detail is compatible
• External eaves-level product; not an internal pipe, adaptor or fan connector
• Not for bathroom/kitchen extraction or soil pipe termination

Ventilation performance

• 10,000mm²/m equivalent free vent area
• Continuous installation helps achieve the required free vent area along the eaves
• Quantity is based on total eaves length and the ventilation requirement for the roof design

Things to consider before buying

• Check whether the roof design requires 10mm or 25mm continuous eaves ventilation
• Use with suitable trays to prevent felt sag blocking the airflow path
• Confirm compatibility with fascia depth, soffit detail and insulation position
• This is for eaves/loft airflow, not powered extraction
